11747 Crimp Die Set Mfg: Thomas & Betts Condition: Used

$125.00

This commercial crimping die manufactured by Thomas and Betts is designed for the following connector size, the codes are as follows, Copper Code 600 kcmil AWG, Flex/24 1100/24, AL/CU 400 kcmil AWG, Color-Keyed Die Color Green, Die Code Number 94H. This die will work in the following Hydraulic Crimping Heads, 13642M, 13642, 13400, or any tooling
Manufacturer: Thomas & Betts
Condition: Used

12 in stock

Description

This commercial crimping die manufactured by Thomas and Betts is designed for the following connector size, the codes are as follows, Copper Code 600 kcmil AWG, Flex/24 1100/24, AL/CU 400 kcmil AWG, Color-Keyed Die Color Green, Die Code Number 94H. This die will work in the following Hydraulic Crimping Heads, 13642M, 13642, 13400, or any tooling made to the Mil Spec MS25441-1. This die can also be used in other manufacturers tooling such as Hydraulic Hand Tool HH80C and Hydraulic Crimping Head TBHD1 by Daniels. Or if the tooling that will accept MS90485-XX, MS23002-XX, MS25442-XX then this die will work in that tooling.This die produces a hex crimp on a 400 MCM non-insulated terminal.
Manufacturer: Thomas & Betts
Condition: Used

Additional information

Weight 3 lbs
